Replacement LCD Screen Display For HP ENVY 15-as 857482-001 15.6 inch FHD 1920x1080 Panel
iProGadgets OEM Repair Parts for HP ENVY 15-as 857482-001 15.6 inch FHD 1920x1080 Laptop Screen Replacement — Quick Answers
Quick answer: this is a replacement display panel for the 857482-001 raw display panel — 15.6″, UWVA / IPS wide viewing angle LCD, 1920 x 1080 px (FHD), 60 Hz, LED backlight, matte, 30-pin eDP with the connector at the bottom right, non-touch, double tested before shipping and backed by a 30-day return window on unused, uninstalled parts. It fits the HP ENVY 15-as and 15T-AS families. Some listings advertise this part for ZBook, ProBook and EliteBook machines — the published machine list for this part number does not include any of those, so please send us your machine model or a photo of the label and we will confirm the fitment before dispatch.
- Fit: Compatible with 15.6″ FHD laptops that use the 857482-001 raw panel, including for HP ENVY 15-as001la / as002la / as003TU / as004la / as005la, the ENVY 15-as1xx series, ENVY Notebook 15T-AS000 and 15T-AS100, plus for HP Notebook 15-ay025TX / 15-ay026TX and for HP Pavilion 15-AU028TX / 15-AU034TX / 15-AU039TX / 15-aw002AX. This is the 60 Hz matte non-touch panel — 120 Hz and faster panels use 40-pin connectors and different codes, and the touch version of this panel is a different assembly. Send us the machine model or a photo of the label and we will confirm before dispatch
- Panel: UWVA (IPS-type, ultra wide viewing angle) LCD, non-touch, matte finish, 30-pin eDP
- Testing: every unit is double tested before shipping — display, backlight and fitment
Technical Specifications
| Item | Detail |
|---|---|
| Part number | For the HP 857482-001 raw display panel |
| Description string | SPS-LCD RAW PANEL 15.6 FHD UWVA BV slim |
| Screen size | 15.6 inches diagonal |
| Resolution | 1920 x 1080 px (FHD) |
| Refresh rate | 60Hz |
| Pixel density | 141 ppi |
| Aspect ratio | 16:9 |
| Panel technology | UWVA / IPS-type, ultra wide viewing angles, transmissive |
| Backlight | LED (White LED), lamp type DIODE |
| Colour depth note | This is a standard-gamut panel. It is not a 72% NTSC wide-gamut panel — if the machine you are working on took a 72% panel, that is a different part and this one will look less colourful |
| Surface | Matte (anti-glare). Supply for this panel is currently matte only — machines that shipped with a glossy panel will change in surface finish when this one is fitted |
| Signal interface | eDP, 30-pin, 0.5 mm pitch, connector at the bottom right of the screen |
| Connector position | Bottom right, viewed from the back of the screen |
| Frame profile | Slim — from HP, this panel sits in the slim / BV family |
| Operating temperature | 0 to 50 °C |
| Touch | Display-only panel (no touch layer) |
| What is not included | Plastic display assembly, frame brackets and screws are not included. No bezel, no hinges, no eDP cable and no digitizer |
| NOT a high-refresh panel | 120 Hz and faster 15.6″ panels use 40-pin connectors and different part codes — they are not covered by this listing |
| Machine model check | The published machine list for this part covers the HP ENVY 15-as and 15T-AS families and several Pavilion notebooks. Listings that also advertise ZBook, ProBook or EliteBook for this part are not supported by the machine list — send us the model and we will check it |
| Condition | Brand-new, unassembled |
| Quality | iProGadgets OEM Quality |
Compatibility
| Device | Model numbers |
|---|---|
| For HP ENVY 15-as series | 15-as001la, 15-as002la, 15-as003TU, 15-as004la, 15-as005la, and the 15-as1xx range |
| For HP ENVY Notebook | 15T-AS000, 15T-AS100 |
| For HP Notebook | 15-ay025TX, 15-ay026TX, 14-am019TU |
| For HP Pavilion | 15-AU028TX, 15-AU034TX, 15-AU039TX, 15-aw002AX, 14-AL018TX |
| Panel codes | 857482-001, 857482 001 |
| Where to confirm fitment | Send the machine model, or a photo of the label on the back of the screen you are removing — we will check it against our stock before dispatch |
Before We Ship — Please Send Us These 3 Details
Laptop, all-in-one and desktop PC screens can differ between revisions of the same model, so the listing alone cannot always tell us which panel is inside your machine. After you place the order we will contact you for the three items below — please send them so we can confirm the fitment and ship the correct, fully compatible screen straight away:
- A photo of your computer. A clear photo of the laptop itself, plus the model / service label on the bottom cover (or the model name shown in Settings → About).
- Touch or non-touch, resolution and refresh rate. Tell us whether your screen is a touch screen or a non-touch screen, its resolution, and its refresh rate in Hz. If you are not sure, just send the model number and we will check it for you.
- Photos of your old screen. Once the machine is opened, a full photo of the back of the old screen and a close-up of the label or barcode sticker on it. That label carries the exact panel part number, which removes any doubt about which screen you need.
We check your photos against our stock before dispatch. If something does not match, we will contact you first instead of sending a part that may not fit. Once your details are confirmed, we arrange shipment within 1 to 3 business days. Thank you for helping us get it right.
Installation Notes
- Clean the flex cable with alcohol before installation and confirm that it is well connected.
- Do not pull, tear or push on the flex cable, be careful during installation.
- Before installing the screen, please remove the battery in advance.
- Please tap the screen carefully, because the screen is too fragile to damage.
Quality Control
Strictly tested by the iProGadgets QC Team — every unit is double tested before shipping: the display is checked for dead pixels and uniformity, the backlight is checked for brightness and flicker, and the connector and flex are checked for fit. Only panels that pass both tests are packed. Quality wording: iProGadgets OEM Quality.
Shipping and Delivery
We ship within 1 to 3 business days after the order is confirmed. Each screen is wrapped in protective foam and packed in a strong corrugated carton to survive transit. We ship worldwide with tracked shipping so you can follow the parcel from dispatch to delivery.
Returns & Warranty
Every panel is covered by a 30-day return window on unused, uninstalled parts. Our warranty is valid until installed — once the screen is fitted we cannot take it back, so please confirm the fitment with us before installation. If the panel arrives damaged or does not match what you ordered, contact us within 30 days and we will make it right.
Questions before you order? Send us the machine model or a photo of the label on the back of the screen you are replacing, and we will confirm the fitment before you buy. Email sales@iProGadget.com — we reply within one business day.
Before We Ship — Please Send Us These 3 Details
Laptop, all-in-one and desktop PC screens can differ between revisions of the same model, so the listing alone cannot always tell us which panel is inside your machine. After you place the order we will contact you for the three items below — please send them so we can confirm the fitment and ship the correct, fully compatible screen straight away:
- A photo of your computer. A clear photo of the laptop itself, plus the model / service label on the bottom cover (or the model name shown in Settings → About).
- Touch or non-touch, resolution and refresh rate. Tell us whether your screen is a touch screen or a non-touch screen, its resolution, and its refresh rate in Hz. If you are not sure, just send the model number and we will check it for you.
- Photos of your old screen. Once the machine is opened, a full photo of the back of the old screen and a close-up of the label or barcode sticker on it. That label carries the exact panel part number, which removes any doubt about which screen you need.
We check your photos against our stock before dispatch. If something does not match, we will contact you first instead of sending a part that may not fit. Once your details are confirmed, we arrange shipment within 1 to 3 business days. Thank you for helping us get it right.
Installation Notes
- Clean the flex cable with alcohol before installation and confirm that it is well connected.
- Do not pull, tear or push on the flex cable, be careful during installation.
- Before installing the screen, please remove the battery in advance.
- Please tap the screen carefully, because the screen is too fragile to damage.
Quality Control
Strictly tested by the iProGadgets QC Team — every unit is double tested before shipping and ships in good working order. After receiving the part, please check the appearance and test it first: connect the new part to the motherboard for a functional test before full installation, and only install once everything works. We are not responsible for any installation mistakes — if you are not experienced with screen replacement, have the part fitted by a professional repair shop.
Shipping
We ship worldwide. Orders are dispatched within 1 to 3 business days, and every package carries a tracking number you can follow on the order page. Delivery typically takes 7 to 10 days after dispatch.
Returns & Warranty
30-day returns on unused, uninstalled parts. The warranty is valid until installed — once a screen has been fitted, the return window no longer applies, which is why we ask you to test before installation.
FAQs
Does this screen fit my ZBook, ProBook or EliteBook?
Send us the model before ordering. Several listings advertise this part number for ZBook, ProBook and EliteBook machines, but the machine list published for the 857482-001 covers the ENVY 15-as / 15T-AS families and a set of Pavilion notebooks — no mobile workstation or EliteBook model appears in it. Those machines use different panels, in many cases 40-pin or 3K resolution. Give us the model and we will tell you what fits.
Will the finish look different from the screen I am replacing?
Possibly, and it is worth knowing before you order. Supply for this panel is currently matte only, while some machines of this type shipped with a glossy panel. If yours is glossy, the new screen will look slightly less reflective and the colours will read a little more softly under indoor lighting. It is a surface finish change, not a defect.
Is this a 72% colour gamut panel?
No. This is a standard-gamut panel. Sellers state plainly that this part is not a 72% NTSC panel, and that matters when you are working on a machine that originally carried a wide-gamut screen — swapping a 72% panel for a standard one makes the colours noticeably flatter. If the machine took a 72% panel, order that part instead and we will confirm from the label.
Is this a touch screen, and what else is in the box?
This is the non-touch display panel only — no touch layer, no digitizer, no bezel, no hinges, no screws, no brackets and no eDP cable. The cable is not included because on most repairs it stays with the machine and is undamaged. If you need a full assembly or a touch version, tell us the machine model and we will tell you what else you need.
Questions about fit, shipping to your country, or bulk pricing? Email sales@iProGadget.com and we will confirm the exact part you need.
Frequently Asked Questions
Is this part compatible with my device?
This listing is for Replacement LCD Screen Display For HP ENVY 15-as 857482-001 15.6 inch FHD 1920x1080 Panel. It is built as a direct-fit replacement for the model named in the title. Match the model number in the title against your own device before ordering. If you are not sure which version you need, email sales@iProGadget.com and we will confirm the correct part for you.
What is the quality of these replacement parts?
We supply iProGadgets OEM Quality / Premium Compatible replacement parts. Every part is manufactured to OEM specifications, so the fit, finish and function match the original component it replaces, and each unit is individually tested before it leaves our warehouse.
Is the part tested before it is shipped?
Yes. Every part we sell is inspected before dispatch and tested wherever testing applies — screen assemblies are checked on the panel, the touch response and the connector. Orders are processed and shipped within 1-3 business days after payment is confirmed.
How long does shipping take?
Orders leave our warehouse within 1-3 business days. Express Shipping (DHL, UPS or FedEx) takes 5-8 working days and is normally used for parcels over 2 kg. Registered Air Post takes 10-20 working days and is normally used for parcels under 2 kg. Every order ships with a tracking number. Customs clearance can add extra time, especially during peak season.
Will I be charged import duties or customs fees?
Customs charges depend on your own country's import rules and its de minimis threshold, not on the seller. Some destinations apply no duty at all on lower-value parcels, and where duty or VAT does apply it is collected by your local post office or courier before delivery. We ship every order with complete and accurate commercial documents, which is what keeps a parcel moving through customs instead of sitting in it. If you would like to estimate the charges before you order, email us your country and we will point you to the right authority.
What is your return policy?
We offer a 30-day return policy, which means you can request a return within 30 days of receiving your item. To be eligible, the item must be unused, uninstalled and in the packaging it arrived in. Once a part has been fitted, bonded or used it cannot be returned, so please test the part before installation. To start a return, email sales@iProGadget.com.
What should I do if the part arrives damaged or faulty?
Inspect your order as soon as it arrives. If an item is defective, damaged or not what you ordered, contact us at sales@iProGadget.com straight away with photos or a short unboxing video, and we will arrange a replacement or a refund.
Do you provide repair guides or installation tutorials?
No. We are a supplier of replacement parts only. We are not a repair shop, and we do not provide repair guides, tutorials or step-by-step installation support. Every part we sell is intended to be installed by a professional technician at a qualified repair shop, which also gives the best result: a technician can transfer the small components, handle the adhesives and test the finished repair. Please do not attempt the installation yourself if you have no previous repair experience, as these assemblies are fragile and incorrect handling can damage them permanently. We sell parts only and do not accept responsibility for installation carried out by the customer. Our warranty covers the part itself and remains valid until the part is installed. If a problem appears after the repair, please take the device back to the repair shop that fitted the part so they can inspect the installation and test the device.
Still have a question about this part? Email us at sales@iProGadget.com and we will confirm compatibility, shipping time or return details for you.
